30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Projection
2.2500
Finish
Satin Nickel Blackened
Grade
ANSI/BHMA Grade 3
Backset
2-3/8 Inch
Keyway
Kwikset KW1
Function
771-Entry
Door Thickness
1-3/8"; 1-1/2"; 1-5/8"; or 1-3/4"
Strike
Round Corner Full Lip
Bore Size
2.1250
Cylinder Type
Conventional Cylinder
Finish Description
Satin Nickel Blackened
Product Length
3.7850
Included Components
Keyed Entry Lock, Keys, lever trim, rose, mounting hardware
Lever Style
SL-Savannah
Keyblank Grouping
YALR-KW1-5-1
Rose/Escutcheon Trim
Round Rose
Door Cross Bore
2.125 Inch
Keying Charges
Residential-Conventional
Product Material
Metal
Product Type
Cylindrical Lock
Box Length
7.0000
Box Width
3.2500
Box Height
2.6300
Warranty
Limited Lifetime Mechanical and Finish Warranty
Color Code
US15A
Application
Entrances and Side Doors
Collection
New Traditions
Latch Type
Adjustable
Strike Type
Full Lip
ADA Compliant
No
Finish Family
Black
Strike Size
2-1/4 Inch
Standards
ANSI/BHMA A156.2; ADA
Faceplate Dimension
1" x 2-1/4"
Door Preparation
Cross Bore 2-1/8"; Edge Bore 1"
Function Description
Both sides locked or unlocked by key outside or push button inside
Function Family
Entry/Entrance/Office
Product Projection
2-1/4 Inch
Features
Constructed From Quality Materials With A Focus On Durability; Easy One Person Installation With Removable Lever And Rosette For Scratch-Free Installation; Concealed Screws For A Clean Look
Manufacturer Parent
Assa Abloy
Door Edge Bore
1 Inch
Box Dimensions (L x W x H)
3.25x7x2.63"
Sub-Series
RL_Lever_Locksets_Yale_Residential_06
With concealed holding screws and a strengthened spindle, New Traditions products reflect an outstanding commitment to quality. Like the New Traditions knobs, the levers are exquisitely designed. With free-flowing curves and smooth edges, the Mesa, Niagara, Savannah, Prairie, Vidalia, and Woodland levers offer impeccable elegance at an exceptional price.
Features:
