Indexable Drill Insert: TCF180508V34 WU40PH, Carbide - pack of 5

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Widia 5542476-XCP5Click To Copy Indexable Drill Insert: TCF180508V34 WU40PH, Carbide - pack of 5

Item #: 5542476-XCP5 by Widia

See reviewsSee reviews
See reviews summary
HURRY! Low in stock

$157.22

/package
SAVE UP TO 15.72

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business dayIn stock: 1 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Insert Material

Carbide

Vendor Drop Ship

N

Iso Code

TCF180508GCV34

Width (Decimal Inch - 4 Decimals)

0.5748

Thickness (Decimal Inch - 4 Decimals)

0.2126

Relief Angle

11

Rake

Positive

Shape

Irregular

Coating/Finish

TiAlN

UNSPSC Code

23242105

Corner Radius (Inch)

1/32

Insert Style

TCF

Insert Hand

Neutral

Hole Diameter

0.2362in

Manufacturer Grade

WU40PH

Inscribed Circle (Inch)

45/64

Length (Decimal Inch - 4 Decimals)

0.5748

Chipbreaker

V34

Inscribed Circle (Decimal Inch)

0.7040

Coating Process

PVD

Primary Workpiece Material

Steel

Corner Radius (Decimal Inch)

0.0315

Compatible Drill Style

TCF

Insert Size Code

180508

Included Angle Degree

90

Number of Cutting Edges

4

ANSI Code

TCF180508GCV34

Series

TCF

Primary Workpiece Material Code

P

Product Overview
Indexable Drill Insert: TCF180508V34 WU40PH, Carbide TiN;TiAlN Coated, 45/64" Inscribed Circle, 0.2126" Thick, 1/32" Corner Radius, 90 degree Irregular Shape
