Widia 3320946Click To Copy Corner Chamfer End Mill: 5/8" Dia, 2-1/4" LOC, 4 Flute, 0.0197" Chamfer Width, Solid Carbide TiCN
Item #: 3320946 by Widia
See reviewsSee reviews
In Stock
$381.28
/eachSAVE UP TO 38.13
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 6 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Flute Type
Helical
Shank Type
Weldon Flat
Number of Flutes
4
Pitch
Normal
Chipbreaker
Yes
Length Type
Regular
Cutting Direction
Right Hand
Series
4S0R
Variable Helix
No
Coating/Finish
TiCN
Coolant Through
No
Length Of Cut (Decimal Inch - 4 Decimals)
2.2500
Length of Cut (Inch)
2-1/4
Manufacturers Catalog Number
TC4S1R16006
Overall Length (Decimal Inch)
5.0000
Overall Length (Inch)
5
Primary Workpiece Material
Steel
Primary Workpiece Material Code
P
Shank Diameter (Decimal Inch)
0.6250
Shank Diameter (Inch)
5/8
UNSPSC Code
27112803
Vendor Drop Ship
N
Centercutting
Yes
Coating Classification
PVD
End Mill Material
Solid Carbide
Extended Reach
No
Flute Direction
Right Hand
Helix Style
Medium
Material Removal Type
Roughing
Mill Diameter (Decimal Inch)
0.6250
Mill Diameter (Inch)
5/8
Single Or Double End
Single
Variable Index
No
Reach Length (Inch)
2-1/4
Chamfer Angle
45
Reach Length (Decimal Inch)
2.2500
Chamfer Length (Decimal Inch)
0.0197
Chamfer Width (Decimal Inch)
0.0197
Product Overview
Corner Chamfer End Mill: 5/8" Dia, 2-1/4" LOC, 4 Flute, 0.0197" Chamfer Width, Solid Carbide 5" OAL, 5/8" Shank Dia, TiCN Coated, Centercutting, Series 4S0R
