Turning Insert: GCHW151505, Carbide - pack of 10

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Widia 2827596-XCP10Click To Copy Turning Insert: GCHW151505, Carbide - pack of 10

Item #: 2827596-XCP10 by Widia

See reviewsSee reviews
See reviews summary
In Stock

$293.30

/package
SAVE UP TO 29.33

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business dayIn stock: 6 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Side Clearance

Positive

Coating Process

PVD

Coating/Finish

TiN

Corner Radius (Decimal Inch)

0.0070

Manufacturers Catalog Number

2827596

Material Grade

Submicron

Primary Workpiece Material

Steel

Primary Workpiece Material Code

P

UNSPSC Code

23242105

Vendor Drop Ship

N

Width (Decimal Inch - 4 Decimals)

0.1875

Width (Inch)

3/16

Coating Classification

PVD

Insert Holding Method

Screw

Insert Length (Decimal Inch)

0.2650

Insert Thickness (Decimal Inch)

0.0930

Maximum Depth of Cut (Decimal Inch)

0.0883

Multi-use Tool

No

Rake

Positive

Secondary Workpiece Material

Cast Iron

Insert Hand

Neutral

Wiper Edge

No

Inscribed Circle (Decimal Inch)

0.1875

Insert Shape

Non-ISO Specialty Shapes

Clearance Code

C

Full Radius

No

Insert Shape Code

G

Secondary Workpiece Material Code

K

Insert Style

GCHW

Insert Size Code

151505

Tolerance Code

H

Hole Diameter (Decimal Inch)

0.0940

Relief Angle

7

Inscribed Circle (Inch)

3/16

Multi-Use Application

Turning

Manufacturer Grade

CG5

Length Range (Decimal Inch)

0.0000 - 0.3000

ANSI Size Code

151505

ISO Insert Code

GCHW

Proprietary Coating Designation

TiN

Iso Code

GCHW060202

ANSI Insert Code

GCHW151505

Cutting Edge Style

Honed

Number of Cutting Edges

4

Standards

ANSI

Included Angle

45

Insert Material

Carbide

Series

GCHW

Product Overview
Turning Insert: GCHW151505, Carbide TiN Coated, Neutral, 0.265" Long, 3/16" Inscribed Circle, 0.0071" Corner Radius, 45 degree Diamond, Series GCHW
