Turning Insert: VNMG 332 TM T9225, Solid Carbide - pack of 10

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Tungaloy 6780704-XCP10Click To Copy Turning Insert: VNMG 332 TM T9225, Solid Carbide - pack of 10

Item #: 6780704-XCP10 by Tungaloy

See reviewsSee reviews
See reviews summary
In Stock

$242.55

/package
SAVE UP TO 24.25

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business dayIn stock: 8 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Iso Code

VNMG 332 TM

Proprietary Coating Designation

Multilayer Coating

Length Range (Decimal Inch)

0.7000 - 10.0000

Manufacturer Grade

T9225

Multi-Use Application

Turning

Inscribed Circle (Inch)

3/8

Relief Angle

0

Hole Diameter (Decimal Inch)

0.1500

Tolerance Code

M

Insert Size Code

332

Insert Style

VNMG

Chip Breaker

TM

Insert Shape Code

V

Full Radius

No

Rake Angle

-6

Clearance Code

N

Insert Shape

Diamond 35

Corner Radius (Inch)

1/32

Inscribed Circle (Decimal Inch)

0.3750

Wiper Edge

No

Insert Hand

Neutral

Rake

Negative

Multi-use Tool

Yes

Maximum Depth of Cut (Decimal Inch)

0.1969

Insert Thickness (Inch)

3/16

Insert Thickness (Decimal Inch)

0.1875

Insert Length (Decimal Inch)

1.3080

Insert Holding Method

Clamp

Coating Classification

CVD

Width (Inch)

3/8in

Width (Decimal Inch - 4 Decimals)

0.3750in

Vendor Drop Ship

N

UNSPSC Code

23242105

Primary Workpiece Material Code

P

Primary Workpiece Material

Steel

Material Grade

P15

Manufacturers Catalog Number

6780704

Corner Radius (Decimal Inch)

0.0315

Coating/Finish

Titanium

Coating Process

CVD

Series

VNMG-TM

Insert Material

Carbide

Included Angle

35degree

Standards

ANSI

Number of Cutting Edges

4

Cutting Edge Style

Sharp

Product Overview
Turning Insert: VNMG 332 TM T9225, Solid Carbide TiN, TiCN, Al2O3 & TiN Coated, Neutral, 0.657" Long, 3/8" Inscribed Circle, 0.0313" Corner Radius, 35 degree Diamond, Series T9200
