Select Hinges SL53 CL HD 83 CONTINUOUS HINGE, HALF SURFACE HEAVY DUTY, 83 INCHES CLEAR ALUMINUM Satin Stainless Steel
Item #: SL53 CL HD 83 by Select Hinges
11 reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Handing
Non-Handed
Door Thickness
1-3/4"
Door Size
48"
Alternate Part Number-1
145894
Hinge Style
Geared, Half Surface
Hinge Rating
200 lbs
Finish Family
Aluminum
Series
SL53 Series
Product Length
83 Inch
Product Material
Aluminum 6063 T6
Product Type
Hinge/Pivot
Hinge Type
Continuous Hinge
Standards
ANSI/BHMA A156.26-2006 Grade 1
Function Family
Hinge/Pivot
Application
Geared Continuous Hinges are Build to Handle Abuse From High Traffic Applications
Bearing Type
Thrust Bearings
ADA Compliant
No
Maximum Door Width
48 Inch
Sub-Series
SL53-83-CL-HD
Function
Continuous Hinge
Hinge Clearance
7/16" Clearance Required for Cap Rotation
For Use With
1-3/8" to 1-3/4" Doors
Finish Description
Aluminum
Manufacturer Parent
Select Products Limited
Hinge Size
83"
Fastener Size
12-24 X 3/4" Self Drilling, Thread Forming 410SS Phillips Undercut Flathead Screws , 1/4-20 Through Bolts, 1/4-20 Shoulder Screws
Product Overview
Hinge failure is the most common cause of entrance failure. The Select Continuous Geared Hinge is a revolutionary development that puts an end to the costly and irritation problems associated with hinge failure. Extruded 6063 T6 Aluminum alloy w/ polyester thrust bearings.
