The CRL SDR Bottom Rolling Sliding Door System with 4" (102 mm) Square Rails Top and Bottom utilizes our popular Wedge-Lock Glass Securing System. The DR4S Series Door Rails are used for all door and fixed panels, and are custom fabricated to your specifications. The doors can be ordered with or without locks in the bottom rail. Maximum door width is 48" (1.22 m); maximum door height is 108" (2.74 m), with a maximum weight not to exceed 234 pounds (106 kg).
DK Hardware Professional Tax Exempt? Net 30? - DK Net Terms
Roll over image to zoom in
Product Features
Product Overview
Related Videos
Reviews
Questions & Answers
CRL 4SDR3DSA Satin Anodized XOX Format Sliding Door Entrance System - 4" Top and Bottom Square Rail
Item #: 4SDR3DSA by CR Laurence
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- With 4" Square DR4S Series Door Rails
Panels
O = Fixed, X = Sliding
Finish
Satin Anodized
Maximum Door Height
108
Maximum Door Width
48
Finish/Color
Satin Anodized
Maximum Panel Weight (Pounds)
234
Height
4
Maximum Panel Weight
234 lbs. (106.1 kg)
Product Overview
The CRL SDR Bottom Rolling Sliding Door System with 4" (102 mm) Square Rails Top and Bottom utilizes our popular Wedge-Lock Glass Securing System. The DR4S Series Door Rails are used for all door and fixed panels, and are custom fabricated to your specifications. The doors can be ordered with or without locks in the bottom rail. Maximum door width is 48" (1.22 m); maximum door height is 108" (2.74 m), with a maximum weight not to exceed 234 pounds (106 kg).
