Robertshaw 790-015 Gas Cooking Control Ignition Board
Item #: 790-015 by Robertshaw
UPC #: 662013101183
See reviews See
reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How
Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Voltage
24 Volt
Warranty
2 Year Warranty
Pack Size
1
Manufacturer Warranty
2 Year Warranty
Accessory/Part Type
Ignition Control
Brand/Model Compatibility
Robertshaw
Full Load Amps
10 Amp
HVAC Product Type
HVAC Part
Product Depth (in.)
3
Product Height (in.)
6.5
Product Width (in.)
5.1
Refrigeration Controls Type
Pre-Purge, Remote, 3 Attempts
Switch Type
SPST
UNSPSC
52141500
The RAM hot surface ignition controls are 24-Volt AC. When the thermostat calls for heat, RAM's HSI control simultaneously energizes the hot surface ignitor and initiates current sensing function. Gas valve(s) remain closed until current sense threshold is reached. Once the current draw threshold has been reached or exceeded, the gas valve(s) and flame rectification circuits are energized. Upon proof of flame, the hot surface ignitor is shut off. Main burner flame is continuously monitored. Loss of flame detection results in RAM-H cycling to check the current draw of the hot surface ignitor. If the hot surface ignitor is below the current draw threshold, the gas valve(s) will remain off and the hot surface ignitor will remain on until the current threshold is reached.
- Electrical rating (input): 24V 50/60 Hz, 50mA
- Gas valve relay ratings: 5.0 Amp
- Ignitor relay ratings: 10.0 Amp
- Temperature range: -40°F to 175°F
- Ignitor: 120-Voly 50/60 Hz
