Schlage J Dexter Series JD81619 One Sided Deadbolt With Plate Satin Nickel Finish with Adjustable Latch and Radius Strike
Item #: JD81619 by Dexter by Schlage
UPC #: 043156893430
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- One-sided Deadbolt Lock with Exterior Plate - Unlocked by Inside Thumbturn
- ANSI/BHMA A156.36 Grade 3
- Reversible Handing
- Includes All Mounting Hardware for Easy Installation
- Lifetime Mechanical & 5 Year Finish Warranty
Finish
Satin Nickel
Function
One Sided with Plate
Series
J Series Deadbolt
Handing
Reversible
Strike
Radius Deadbolt Strike
Backset
2-3/8" or 2-3/4"
Grade
ANSI/BHMA Grade 3
Style
Round
Application
Residential
Warranty
Lifetime Mechanical and 5 yr Finish
Color Code
619/US15
Door Thickness
1-3/8" to 1-3/4"
Finish Description
Satin Nickel
ADA Compliant
No
Finish Family
Satin Nickel
Included Components
Deadbolt; Roses; Latch; Strike; Mounting Hardware
Rose/Escutcheon Trim
Round Rose
Product Material
Zinc
Standards
ANSI/BHMA A156.36-2010
Function Family
Blank With Thumbturn Deadbolt
Features
Deadbolt Thrown or Retracted From Interior Side Only; Dual Option Latches
Product Type
Auxiliary Lock
Manufacturer Parent
Allegion
Box Dimensions (L x W x H)
2.8x3.11x3.31
Sub-Series
RL_Deadbolts_Schlage_Residential_19
Product Overview
J SeriesDeadbolts
With premium metal construction and plated keyways, Schlage mechanical and electronic deadbolts are made with durability in mind. Combine our wide range of unique finish and style options with our easy one-tool installation and you can give your door a stylish makeover in minutes.
Available Functions: JD60 - Single Cylinder Deadbolt Lock:- Deadbolt thrown or retracted by key from outside or by inside turn unit
- Bolt automatically deadlocks when fully thrown
- Deadbolt thrown or retracted from interior side only
- Deadbolt thrown or retracted from interior side only
- *Caution: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
- 16-068 - Dual Option (Round, Drive-in) - Standard
- 10-267 - One Radius Deadbolt Full Lip Strike (10-102)
& One Radius Deadbolt Strike (10-103) - Standard - 10-099 - Square Strike Plate & Strike Frame Reinforcer
- ANSI/BHMA A156.36-2010 Commercial Grade 3
- Dual Option: 1" x 2 1/4", 1/4" round faceplate, drive-in latch, 1" housing diameter, 1" throw
- 1" x 2 1/4" round corner and radius corner, full lip
- Adjustable for 2 3/8" or 2 3/4"
- 5-pin, C keyway, keyed alike (KA4)
- 1 3/8" - 1 3/4"
- Two brass cut keys per lock, 5-pin, C section
- Bright Brass (US3)
- Antique Brass (US5)
- Satin Nickel (US15)
- Antique Pewter (US15A)
- Matte Black (US19)
- Bright Chrome (US26)
- Satin Chrome (US26D)
- Satin Stainless Steel (US32D)
- Aged Bronze
- *Non-standard finishes are not available
- Full-color swatch examples available on inside Deadbolts tab
