Pump 5-ASP-LL 1/6 HP 25 gpm Aluminum Diaphragm Switch AC Hydroponic

Roll over image to zoom in

Little Giant 505717 Pump 5-ASP-LL 1/6 HP 25 gpm Aluminum Diaphragm Switch AC Hydroponic

Item #: 505717 by Franklin Electric Co., Inc

UPC #: 029753004653

See reviewsSee reviews
HURRY! Low in stock

$309.24

/each
SAVE UP TO 30.92

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business day
QTY
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Features

Height

8.07"

AMPS

2 amps

Volts

115 V

Depth

4.29"

Width

7.75"

Cord Length

18 ft.

Warranty

1 Year

Horsepower

1/6 HP

Powered By

AC

Phase

Single-Phase

Maximum Temperature

120 °F

Motor Type

Submersible

Pump Type

Hydroponic

Seal Type

Retainer

Protection

IP68

Intake

Bottom Suction

Discharge

1"

Agency Compliance

CSA and UL

Defective Code

A

Discharge Type

Threaded - FNPT

Each Weight

9.180 LB

Hazardous Material

No

Impeller Material

Nylon

Impeller Type

Semi-Open

Maximum Discharge Flow

25 gpm

Maximum Feet of Head

26 ft.

Minimum Temperature

35 °F

Motor Cooling

Water

Pump Length

7.75"

Pump Switch Type

Diaphragm Switch

Returnable

Yes

Seal Material

Viton Retainer

Stages

1

Sub Brand

5-ASP-LL

Sump Pump Outlet Diameter

1"

Velocity

N

Housing Material

Aluminum

Product Type

Pump

Switch Type

Automatic

Pump Base Material

Plastic

Intake Screen Material

Nylon

Motor Shaft End - Material

Stainless Steel

Bottom Bearing Type

Sleeve Bearing

Pump Volute Material

Nylon

Top Bearing Type

Sleeve

Product Overview
The 5-Series is one of the most compact utility pumps on the market. Ideal for light commercial and multi-purpose residential where water removal, transfer or circulation is required.
