Irwin 4935108-XCP5Click To Copy Jobber Drill Bit, 1/4 in Dia, 4 in OAL, Spiral Flute, 1-Flute, 1/4 in Dia Shank, Straight Shank Oxide - pack of 5
Item #: 4935108-XCP5 by BLACK & DECKER US INC
See reviewsSee reviews
In Stock
$39.78
/packageSAVE UP TO 3.98
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 177 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Carbide tip has a unique diamond-ground, four-facet design with sharper cutting edges for centered starts with no walking, fast drilling and excellent hole quality in a variety of materials
- Double-milled flute ensures fast, efficient removal of drilling dust and debris to increase speed and prevent clogging
- Compatible with all standard 1/2 in and 3/8 in chuck drills
Drill Diameter
1/4"
Shank Type
Straight
Returnable
Yes
Defective Code
A
Drill Size
5/16"
Number in Package
1 pc
Packaging Type
Carded
Overall Length
4"
Product Type
Percussion Drill Bit
Material
Diamond
Flute Length
3"
Each Weight
0.100 LB
Velocity
X
Hazardous Material
No
Diameter
1/4"
Finish
Oxide
Application
For rotary drilling
Shank Length
1"
Shank Diameter
1/4"
Flute Type
Spiral
Number of Flutes
1
Point Angle
135 deg
Nomenclature
4935108 MULTI BIT 1/4 4
Applicable Materials
Marble Metal Plastic Wood
Point Type
Split
Overall Length (mm)
101.60
Cutting Direction
Right Hand
Series
49351
Drill Bit Material
HSS
Spiral Type
Regular
Tool Application
Drilling
Coating/Finish
Bright/Uncoated
Coolant Through
No
Double Margin
No
Drill Bit Grade
General Purpose
Drill Bit Size (Decimal Inch)
0.2500
Drill Bit Size (Inch)
1/4
Drill Bit Size Range (Decimal Inch)
0.2500 - 0.3000
Drill Point Angle (Degrees)
135
Flute Length (Decimal Inch)
2.7500
Flute Length (Inch)
2-3/4
Flute Length (mm)
69.85
Maximum Drilling Depth (Decimal Inch)
2.7500
Maximum Drilling Depth (Inch)
2-3/4
Number of Flats
0
Overall Length (Decimal Inch)
4.0000
Overall Length (Inch)
4
Shank Diameter (Decimal Inch)
0.2500
Shank Diameter (Inch)
1/4
Shank Diameter (mm)
6.35
Tool Performance
General Purpose
UNSPSC Code
23241634
Vendor Drop Ship
N
Maximum Drilling Depth (mm)
69.85
Specification Designation
ANSI
Nom. Width
3.335 in
Nom. Height
3.335 in
Nom. Length
5.525 in
Overall Length [Nom]
4 in
Product Overview
MULTI MATERIAL BIT 1/4 4
IRWIN Multi-material drill bits drill through just about any type of material like brick, block, tile, metal, wood, plastic and marble, they'll even drill through multiple materials at the same time. These versatile bits are designed specifically for rotary drilling, but are tough enough to be used with hammer drills.
