Corner Radius End Mill: 3/8" Dia, 1" LOC, 0.5 mm Radius, 3 Flutes, Solid Carbide Zplus

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Helical Solutions 29302Click To Copy Corner Radius End Mill: 3/8" Dia, 1" LOC, 0.5 mm Radius, 3 Flutes, Solid Carbide Zplus

Item #: 29302 by Helical Solutions

See reviewsSee reviews
See reviews summary
In Stock

$106.85

/each
SAVE UP TO 10.69

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business dayIn stock: 46 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Shank Type

Straight-Cylindrical

Shank Diameter (Inch)

3/8

Corner Radius (mm)

0.50

Variable Helix

No

Vendor Drop Ship

N

Length Of Cut (Decimal Inch - 4 Decimals)

1.0000

Overall Length (Inch)

3

TIR Maximum (Decimal Inch)

0.0003

Secondary Workpiece Material

Steel

For Use With

High Precision Toolholder

Mill Diameter (Inch)

3/8

Overall Length Tolerance

-0.0620 to 0.0620 in

Material Removal Type

Roughing

Coating/Finish

Zplus

UNSPSC Code

27112803

Proprietary Coating Designation

Proprietary

Number of Flutes

3

Corner Radius Tolerance

-0.0020 to 0.0020 in

Length of Cut (Inch)

1

Chipbreaker

Yes

Secondary Workpiece Material Code

P

Mill Diameter (Decimal Inch)

0.3750

Primary Workpiece Material

Non-Ferrous Metal

End Type

Corner Radius

Corner Radius (Decimal Inch)

0.0200

Flute Type

Helical

Length Type

Regular

Extended Reach

No

Helix Style

High

Overall Length (Decimal Inch)

3.0000

Coolant Through

No

Mill Diameter Tolerance

h6

End Mill Material

Solid Carbide

Coating Classification

PVD

Flute Direction

Right Hand

Centercutting

Yes

Cutting Direction

Right Hand

Material Application

Aluminum

Shank Diameter (Decimal Inch)

0.3750

Pitch

Coarse

Shank Diameter Tolerance

h6

Series

H45AL-C-3

Single Or Double End

Single

Variable Index

No

Primary Workpiece Material Code

N

Product Overview
Corner Radius End Mill: 3/8" Dia, 1" LOC, 0.5 mm Radius, 3 Flutes, Solid Carbide 3" OAL, 3/8" Shank Dia, 45 degree Helix, Zplus Coated, Single End, Centercutting
