Corner Radius End Mill: 1/8" Dia, 1/2" LOC, 0.5 mm Radius, 2 Flutes, Solid Carbide Bright/Uncoated

Roll over image to zoom in

Harvey 46420Click To Copy Corner Radius End Mill: 1/8" Dia, 1/2" LOC, 0.5 mm Radius, 2 Flutes, Solid Carbide Bright/Uncoated

Item #: 46420 by Harvey

See reviewsSee reviews
See reviews summary
In Stock

$40.96

/each
SAVE UP TO 4.10

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business dayIn stock: 7 units available
QTY
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Features

For Use With

Toolholders

Flute Type

Spiral

Material Application

Aluminum

Shank Type

Straight-Cylindrical

End Type

Corner Radius

Number of Flutes

2

Pitch

Coarse

Chipbreaker

No

Length Type

Long

Cutting Direction

Right Hand

Series

Miniature End Mills - Corner Radius - Stub & Standard

Variable Helix

No

Coating/Finish

Bright/Uncoated

Coolant Through

No

Corner Radius (Decimal Inch)

0.0200

Length Of Cut (Decimal Inch - 4 Decimals)

0.6250in

Length of Cut (Inch)

1/2in

Overall Length (Decimal Inch)

1.5000in

Overall Length (Inch)

1-1/2in

Primary Workpiece Material

Steel

Primary Workpiece Material Code

P

Shank Diameter (Decimal Inch)

0.1250

Shank Diameter (Inch)

1/8in

UNSPSC Code

27112803

Vendor Drop Ship

N

Centercutting

Yes

Coating Classification

Uncoated

End Mill Material

Solid Carbide

Extended Reach

No

Flute Direction

Right Hand

Material Removal Type

Roughing & Finishing

Mill Diameter (Decimal Inch)

0.1250in

Mill Diameter (Inch)

1/8in

Single Or Double End

Single

Variable Index

No

Mill Diameter Tolerance

0.0000/-0.0020 in

Overall Length Tolerance

0.0100/-0.0000 in

Corner Radius Tolerance

0.0010 to -0.0010 in

Corner Radius (mm)

0.50

Proprietary Coating Designation

Uncoated

Product Overview
Corner Radius End Mill: 1/8" Dia, 1/2" LOC, 0.5 mm Radius, 2 Flutes, Solid Carbide 1-1/2" OAL, 1/8" Shank Dia, 30 degree Helix, Bright/Uncoated, Single End, Series Miniature End Mills - Corner Radius - Stub & Standard
