Jackson Exit Devices are universally recognized as the standard for aluminum storefront hardware. This crossbar designed with simplicity in mind, yet it will provide many years of smooth, reliable operation. Available in both a Rim and Concealed Vertical Rod version this device is suitable for use with 1-3/4" (44.5 mm) narrow, medium, and wide stile aluminum, wood, or hollow metal doors. The 48" (1.22 m) long contoured crossbar is field sizeable, and the device is shipped to fit up to 84" (2.13 m) tall door. Extensions for taller doors are available. The 10 Series Exit Device is the perfect solution when considering a reliable maintenance free means to satisfy life safety requirements.
This device is supplied standard with a 48" crossbar for use with doors up to 48" wide. The customer can cut the bar to exact length needed. For Locking Outside Entry: Use 8500LV02313 Locking Lever Trim or Cylinder Only: Use DL2170 OR DRA50 Type Mortise Cylinder with MS Cam - Will Require use of 3089610958313 Cylinder Mounting Pad. Panic Ships Standard for use with 7/0 (84") doors. Taller doors require use of Extension No. 301347 Top Rod Extender in 12" increments.
FEATURES:
Standard 36" (914 mm) Wide Door - Field Sizeable up to 48" (1.22 m) Width Available on Special Order
Standard Door Height 84" (2.13 m) Extension Available
Concealed Easy-to-Use Dogging System Optional Cylinder Dogging Available on Special Order
Wear Points Insulated by Nylon Sleeves and Rollers
For additional information, contact DK Hardware Sales.
DK Hardware Professional Tax Exempt? Net 30? - DK Net Terms
Roll over image to zoom in
Product Features
Product Overview
Related Videos
Reviews
Questions & Answers
Jackson 31108547313 Dark Bronze 48" 10 Series Non-Handed Concealed Vertical Rod Panic Exit Device
Item #: 31108547313 by Jackson
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Concealed Fastening for Added Security
- Designed for Use with 1-3/4" (44.5 mm) Narrow, Medium and Wide Stile Aluminum, Wood or Hollow Metal Doors
Handing
Non-Handed
Brand
Jackson
Size
48" (1.22 m)
Type
Concealed Vertical Rod
Finish
Dark Bronze
For Door Thickness
1-3/4 Inch
Door Height
7 Inch, 1-1/8 Inch x 2-1/4 Inch, Square Corner.
Manufacturer Parent
CRH
Device Rating
Panic Exit Hardware
Finish Description
Dark Bronze Anodized
Stile
Narrow, Medium or Wide
For Door Height
7 Foot
Function
Exit Only
Sub-Series
EDT_Concealed_Ver_Rod_Devices_CRL_Jackson_1
Fire Rated
No
ADA Compliant
No
Application
Narrow, Medium and Wide Stile Doors
Device Type
Concealed Vertical Rod Device
Length
4
Function Family
Exit Only Device
Standards
ANSI A156.3; UL305 Listed
Device Length
48 Inch (4 Foot)
Product Type
Exit Device
Features
Nylon Sleeves and Rollers Insulated Wear Points
Dogging Options
Hex Key Dogging
Series
1085 Panic Device
Door Material
Aluminum, Wood; Hollow Metal
Finish Family
Dark Bronze
Door Width
48"
Door Type
Aluminum, Hollow Metal, Wood
exit device type
CVR - Concealed Vertical Rod
Bar Style
Crossbar
Alternate Part Number-1
109380
Product Overview
Jackson Exit Devices are universally recognized as the standard for aluminum storefront hardware. This crossbar designed with simplicity in mind, yet it will provide many years of smooth, reliable operation. Available in both a Rim and Concealed Vertical Rod version this device is suitable for use with 1-3/4" (44.5 mm) narrow, medium, and wide stile aluminum, wood, or hollow metal doors. The 48" (1.22 m) long contoured crossbar is field sizeable, and the device is shipped to fit up to 84" (2.13 m) tall door. Extensions for taller doors are available. The 10 Series Exit Device is the perfect solution when considering a reliable maintenance free means to satisfy life safety requirements.
This device is supplied standard with a 48" crossbar for use with doors up to 48" wide. The customer can cut the bar to exact length needed. For Locking Outside Entry: Use 8500LV02313 Locking Lever Trim or Cylinder Only: Use DL2170 OR DRA50 Type Mortise Cylinder with MS Cam - Will Require use of 3089610958313 Cylinder Mounting Pad. Panic Ships Standard for use with 7/0 (84") doors. Taller doors require use of Extension No. 301347 Top Rod Extender in 12" increments.
FEATURES:
Standard 36" (914 mm) Wide Door - Field Sizeable up to 48" (1.22 m) Width Available on Special Order
Standard Door Height 84" (2.13 m) Extension Available
Concealed Easy-to-Use Dogging System Optional Cylinder Dogging Available on Special Order
Wear Points Insulated by Nylon Sleeves and Rollers
For additional information, contact DK Hardware Sales.
