Turning Inserts; ANSI Insert Code: VNMG332 ; ISO Insert Code: VNMG160408 ; Relief Angle: 0 ; Insert Style: VNMG ; Corner Radius (Decimal Inch): 0.0079 ; Included Angle: 80

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Ceratizit 75022218Click To Copy Turning Inserts; ANSI Insert Code: VNMG332 ; ISO Insert Code: VNMG160408 ; Relief Angle: 0 ; Insert Style: VNMG ; Corner Radius (Decimal Inch): 0.0079 ; Included Angle: 80

Item #: 75022218 by Ceratizit

See reviewsSee reviews
See reviews summary
In Stock

$40.00

/each
SAVE UP TO 4.00

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business dayIn stock: 10 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Number of Cutting Edges

2

Included Angle

80

Insert Material

Carbide

Series

VNMG

Side Clearance

Negative

Coating Process

PVD

Coating/Finish

TiAlTaN

Corner Radius (Decimal Inch)

0.0079

Primary Workpiece Material

Stainless Steel

Primary Workpiece Material Code

P

UNSPSC Code

23242105

Vendor Drop Ship

N

Insert Holding Method

Screw

Insert Thickness (Decimal Inch)

0.0937

Maximum Depth of Cut (Decimal Inch)

0.2520

Rake

Negative

Secondary Workpiece Material

Superalloy

Insert Hand

Neutral

Wiper Edge

No

Inscribed Circle (Decimal Inch)

0.2500

Insert Shape

V - Diamond (Rhombic) 35-Deg

Clearance Code

N

Insert Shape Code

V

Chip Breaker

F30

Secondary Workpiece Material Code

S

Insert Style

VNMG

Insert Size Code

332

Tolerance Code

M

Hole Diameter (Decimal Inch)

0.1102

Relief Angle

0

Inscribed Circle (Inch)

1/4

Manufacturer Grade

CTPM125

ISO Size Code

160408

Grade Characteristics

Steel (P) - Moderate Wear-Resistance and Toughness to High Toughness

ANSI Size Code

332

ISO Insert Code

VNMG160408

Iso Code

VNMG 160408EN-F30 CTPM125

ANSI Insert Code

VNMG332

Product Overview
Turning Inserts; ANSI Insert Code: VNMG332 ; ISO Insert Code: VNMG160408 ; Relief Angle: 0 ; Insert Style: VNMG ; Corner Radius (Decimal Inch): 0.0079 ; Included Angle: 80
