Milling Insert: XDKT 11T308SR-M50 CTPP235, CTPP235, Solid Carbide TiAl

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Ceratizit 51037108Click To Copy Milling Insert: XDKT 11T308SR-M50 CTPP235, CTPP235, Solid Carbide TiAl

Item #: 51037108 by Ceratizit

See reviewsSee reviews
See reviews summary

$26.83

/each
SAVE UP TO 2.68

Buying in bulk

Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Cutting Edge Style

Chamfered

Material Application

Steel

ANSI Code

XDKT 11T308SR-M50 CTPP235

Number of Cutting Edges

2

Standards

ANSI

Insert Material

Solid Carbide

Series

XDKT

Coating Process

PVD

Coating/Finish

TiAl

Corner Radius (Decimal Inch)

0.0315

Length (Decimal Inch - 4 Decimals)

0.4173

Manufacturers Catalog Number

XDKT 11T308SR-M50 CTPP235

Material Grade

P35

Primary Workpiece Material

Steel

Primary Workpiece Material Code

P

Thickness (Decimal Inch - 4 Decimals)

0.1496

UNSPSC Code

23291601

Vendor Drop Ship

N

Width (Decimal Inch - 4 Decimals)

0.2677

Coating Classification

PVD

Insert Holding Method

Screw

Maximum Depth of Cut (Decimal Inch)

0.2835

Multi-use Tool

Yes

Rake

Positive

Secondary Workpiece Material

Stainless Steel

Insert Hand

Right Hand

Inscribed Circle (Decimal Inch)

0.2677

Corner Radius (Inch)

1/32

Insert Shape

Parallelogram

Chip Breaker

M50

Secondary Workpiece Material Code

M

Insert Style

XDKT

Insert Size Code

11T308

Hole Diameter (Decimal Inch)

0.1102

Relief Angle

15.00

Included Angle Degree

90

Cutting Edge Effective Length (Decimal Inch)

0.4173

Manufacturer Grade

CTPP235

Inscribed Circle Range (Decimal Inch)

0.2500 to 0.3000

Single or Double Sided Insert

Single

Cutter Series Compatibility

211-11

Length Range (Decimal Inch)

0.4000 to 0.4500

Thickness Range (Decimal Inch)

0.1250 to 0.1500

Iso Code

XDKT 11T308SR-M50 CTPP235

Product Overview
Milling Insert: XDKT 11T308SR-M50 CTPP235, CTPP235, Solid Carbide Coated, 0.1496" Thick
