Eaton BD2020 Circuit Breaker with Rejection Tab, Duplex, Type BD, 20 A, 1 -Pole, 120 V, Instantaneous Trip
Item #: BD2020 by Eaton Corporation
UPC #: 786676369251
1 1
reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How
Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Voltage
120/240
Mounting Type
Plug
Warranty
10 years
Certifications
UL
Amperage
20 Amp
Phase
Both
Manufacturer Warranty
10 years
Breaker Type
Tandem
Certifications and Listings
ANSI Certified, CSA Certified, UL Listed
Circuit Breaker Type
Duplex
Maximum Amperage
20
Number of Poles
1
Product Depth (in.)
2.89
Product Height (in.)
3.1
Product Width (in.)
0.98
Pack Size
1
UNSPSC
39121601
Packaging Type
Bulk
Indoor or Outdoor
Indoor
Circuit Protection Type
Tandem
CSA Listed
Yes
Defective Code
A
Each Weight
0.370 LB
Hazardous Material
No
Returnable
Yes
Standard overload and short circuit protection in
Standard overload and short circuit protection in Cutler-Hammer, Westinghouse, Bryant, Challenger or Sylvania load centers. for CTL (circuit limiting) load centers with bus bar slots
Sub Brand
Cutler-Hammer
Velocity
B
Alternative UPC
786676369251
Volts
120/240 V
Depth
3"
Width
0.28
UL Listed
Yes
Height
0.08
AMPS
20/20 amps
Product Type
Circuit Breaker
Length
0.32
ECCN
EAR99
Country Origin Code
DO
Wire Size
14 to 4 AWG
Number of Spaces
1
Trip Type
Instantaneous
Operating Temperature
40 deg C
Type
Duplex Type BD
Operating Frequency
50/60 Hz
Application
For overload and short circuit protection of home electrical system
Current Rating
20 A
Actuator Type
Magnetic Thermal
Terminal Type
Feed-Thru
Interrupt Rating
10 kA
Dimensions
3.1 in L x 0.98 in W x 2.89 in H
Nomenclature
BD2020 TWN CIRC BREAKER 20A
Number of Phases
1
CIRCUIT BRKR BD 1P DPLX 20/20A
Specifications:
Specifications:
Suitable for: Overload and Short Circuit Protection of Home Electrical System
Switching duty rating, duplex type breaker requires 1 in per breaker. Thermal magnetic 40 deg C breakers have rejection tab feature, allows only 42 circuits in the panel in compliance with NEC article 384-15. Interchangeable will replace Bryant, Challenger and Westinghouse. Type BR 120/240 V. 10,000 AIR. 1 in per breaker.
